Create a complete 'ggplot' appropriate to a particular data type

This function generates a complete 'ggplot' object suitable for visualizing time series data in an aedseo_tsd object. It creates a line plot connecting the observations and adds points at each data point.

Usage

autoplot(object, ...)

# S3 method for aedseo_tsd
autoplot(object, ...)

# S3 method for aedseo
autoplot(object, linewidth = 0.7, size = 2, alpha = 0.3, width = 0.2, ...)

Arguments

object: An aedseo_tsd or aedseo object
...: Additional arguments (not used).
linewidth: Numeric, the width of the line for the growth rate
size: Numeric, size of observational points.
alpha: Numeric, the alpha (transparency) for the observations with a significantly positive growth rate.
width: Numeric, the width of the error bar employed to show the confidence interval of the growth rate estimate.

Value

A 'ggplot' object for visualizing the time series data.

Examples

# Create an example aedseo_tsd object
aedseo_tsd_object <- tsd(
  observed = c(100, 120, 150, 180, 220, 270),
  time = as.Date(c(
    "2023-01-01",
    "2023-01-02",
    "2023-01-03",
    "2023-01-04",
    "2023-01-05",
    "2023-01-06"
  )),
  time_interval = "day"
)

# Create a ggplot visualization for the aedseo_tsd object
autoplot(aedseo_tsd_object)


# Create an aedseo object
aedseo_object <- aedseo(
  tsd = aedseo_tsd_object,
  k = 3,
  level = 0.95,
  family = "quasipoisson"
)

# Create a ggplot visualization of growth rates with confidence intervals
autoplot(aedseo_object, linewidth = 1, alpha = 0.2)

#> Warning: Using alpha for a discrete variable is not advised.
